High-performance Xtreme button clutch kit featuring a lightweight chromoly flywheel and integrated clutch slave cylinder—engineered specifically for the 2018 and newer Hyundai i30 N and N Performance models equipped with the 2.0L turbocharged engine.

Description

Xtreme Street brings racetrack-developed technology to your road car. Xtreme have performance clutch systems for street vehicles, ranging from heavy-duty organic systems, with OEM (or sometimes better than!) levels of drivability, right through to track-driven road registered race cars.

The Stage 2 clutch uses an upgraded pressure plate combined with a ceramic friction disc in sprung configurations. The stage two clutch range is designed for road and track going vehicles that require a higher torque capacity and temperature tolerance, and faster engagement. Clutch engagement is more aggressive than stage 1, so it is not recommended for daily driven vehicles.

These kits feature a high-quality cover with increased clamping force compared with standard, between 20-40% depending on the demands of the individual vehicle. They use a ceramic “paddle” friction disc which can result in more noise and harsher engagement.

Specifications:

• Flywheel Step: -9.53
• Clutch Disc Diameter (mm): 240
• Clutch Disc Spline Count: 23
• Clutch Disc Spline Diameter (mm): 26
• Disk Type Sprung
• Friction Material Ceramic
• Stage 2R
• Recommended Use Track
• Clamping Force Increase 65%
• Torque (Nm) Inc FOS 910
• Torque (ftlbs): 670
• Fly Wheel Included Yes Single Mass
• Fly Wheel Bolts Included Yes
• Pressure Plate Bolts Included Yes
• Concentric Slave Included Yes
• Spline Grease Yes
• Weight (kg): 13.45

Vehicle Compatibility:

– Hyundai i30N PDe Hatch 2.0L Turbo G4KH (2018-)
– Hyundai i30N CN7 Sedan 2.0L Turbo G4KH (2021-)
– Hyundai i30 Fastback N Performance 2.0L Turbo PDe G4KH (2019-2022)
