Description
The Stage 2 clutch uses an upgraded pressure plate and a ceramic friction disc in a cushioned configuration.
The Stage 2 clutch range is designed for road- and track-going vehicles that require higher torque capacity, temperature tolerance, and faster engagement. Clutch engagement is more aggressive than stage 1, so it is not recommended for daily-driven vehicles.
These kits feature a high-quality cover with a clamping force increased by 20-40% compared with standard, depending on the individual vehicle’s demands. They use a ceramic friction disc with multiple segments to provide a similar working temperature range as ‘1B’ discs, but with slightly smoother engagement.
This kit is used less frequently, but it is available for situations such as low-speed trials, tracks where the operator encounters temperatures that are too high for organic and consequently need a higher-temperature clutch, but with better modulation than ‘1B’. Usually, customers only purchase this option if they have previously used a ‘1A’ and found it insufficient due to the operator’s driving style or the particular demands of the vehicle.
Product Specifications:
- Flywheel Step (mm): +0.5
- Clutch Disc Diameter (mm): 236
- Clutch Disc Spline Count: 23
- Clutch Disc Spline Diameter (mm): 26
- Disc Type: Sprung
- Friction Material: Ceramic
- Stage: 2
- Recommended Use: Track
- Clamping Force % Increase: 40%
- Torque (Nm) Inc FOS: 730
- Torque (ftlbs) Inc FOS: 540
- Spigot Bush/Bearing Included: Yes
- Aligning Tool Included: Yes
- Spline Grease Included: Yes
- Transport Weight (kg): 8.9
Vehicle Compatibility:
– Mazda RX-7 FD3S 13B-REW 1992 – 2002
