Tomei RB26DETT Turbo Outlet Dump Pipe Set – Compatible with Nissan Skyline GT-R R32, R33, R34 & C34 Stagea 260RS

Description

The new model is designed to clear the air intake piping and the turbo compressor housing without the concaves from the previous model which helps even smoother exhaust flow. The new model is made of high-quality SUS316 material instead of the SUS304 from the previous model to withstand even more severe conditions.

Specifications:

• Material: SUS316
• Exit Diameter: Approx. 66mm
• Pipe Thickness: Approx. 2.8mm
• Flange Thickness: Approx. 11mm
• Volume: Front – 800cc / Rear – 900cc
• Weight: Front – 1.85kg / Rear – 2.10kg

Wide mouth design & Step-less connection with a 70mm front pipe.

Dumps the exhaust gas from the turbo straight onto the front pipe without reducing the flowing speed.

Wrenching clearance for easy installation.

Designed to be a hassle-free installation. We have incorporated a dimple in the pipe where the bolt for the flange is located. To allow ease of access to both bolts and nuts to allow a quick, trouble-free bolt-on application.

Kit Contents:

Outlet Pipes (Front & Rear))

Rear Outlet Pipe Gaskets (Front Pipe Side）

Blind Bolt

Nuts

Stud Bolts

O2 Adaptors (For use BNR32)

Vehicle Compatibility:

– Nissan BNR32 Skyline GTR
– Nissan BCNR33 Skyline GTR
– Nissan BNR34 Skyline GTR
– Nissan WGNC34 Stagea 260RS
