High-Performance Organic Clutch and Single-Mass Flywheel for BMW E82, E88, E92, and E93 with 6-Bolt Crankshaft

Description

The Stage 1 clutch kit uses an upgraded pressure plate with increased clamping pressure, combined with an organic friction disc. Stage 1 delivers substantial increases in performance and power holding capability whilst retaining near factory type driveability, and is designed primarily for high-performance road-going vehicles.

These kits feature a high-quality cover with increased clamping force compared with standard, between 20-40% depending on the demands of the individual vehicle.

They use an organic friction disc to retain driveability similar to standard.

– Xtreme Heavy Duty Clutch & Solid Flywheel Conversion Kit
– Replaces Factory Dual Mass Flywheel
– Conversion Kit & Solid Type Flywheel Included
– Heavy Duty Organic Type
– Designed For Street Use

Product Specifications:

Flywheel Step (mm) -9.53

Clutch Disc Diameter (mm) 240

Clutch Spline Count 26

Clutch Disk Spline Diameter (mm) 35

Disc Type Sprung

Friction Material Organic

Stage 1

Recommended Use Street

Clamp Force % Increase 70%

Torque (Nm) Inc FOS 600

Spigot Bush/Bearing Included Yes

Aligning Tool Yes

FlyWheel Yes

FlyWheel Bolts Yes

Pressure Plate Bolts Yes

Please Note This Kit Will Convert Your Vehicle To Single Mass FlyWheel

Vehicle Compatibility :

– BMW 135i E82 12/2008-2010 N54B30A 6-bolt Crank 3.0L L6 DOHC VVT

– BMW 136i E88 12/2008-2010 N54B30A 6-bolt Crank 3.0L L6 DOHC VVT

– BMW 335i E92/E93 12/2008-2010 N54B30A 6-bolt Crank 3.0L L6 DOHC VVT

– BMW 335i E91 12/2008-2010 N54B30A 6-bolt Crank 3.0L L6 DOHC VVT
